Powerful
Setting new standards, this single-sided, full color card printer is loaded with user-friendly features and dynamic options, which make it the most powerful and flexible printer in its class.

Reliable
With its new, innovative highly reliable angled feeder design (patent pending), there is simply no better choice than the P330i for mission critical applications.

Flexible
Designed to integrate seamlessly in a wide variety of applications, the P330i comes standard with an LCD and offers a full range of options, including build-in Ethernet.

Zebra i Series Intelligent Printing System
The P330i also features the benefits of enhanced Series functionality. i Series printers are designed to make card printing a simple function for all users.

The system features:

Advanced RFID Technology
Automatic Driver Configuration
Intelligent Color Optimization
Ribbon Image Counter & Ribbon Low Notification
Enhanced Ribbon Formulation

General Specifications
High speed printing
144 cards/hour for color, single side (YMCKO)
600 cards/hour for resin black (K)
Windows® Drivers: 2000, XP, Server 2003; Vista compatible
Two (2) year warranty on card printer and original printhead (unlimited passes) - if shipped on or after January 1, 2007
One (1) year warranty applies to printers shipped prior to January 1, 2007

Color Printing
Color dye sublimation or monochrome thermal transfer printing
25 seconds per card full color single sided (YMCKO)
300 dpi (11.8 dots/mm) print resolution

Bar Codes
Code 39
Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Interleaved
UPC-A
EAN 8 & EAN 13
PDF-417 2D bar code and other symbologies can be printed via Windows® drivers.

Fonts
True Type fonts via Windows drivers.

Card Specifications
Types: PVC, PVC Composite, UHF Gen 2 RFID, Adhesive backed
Card width/length: ISO CR-80 - ISO 7810, 2.12" (54mm) X 3.385" (86mm)
Magnetic Stripe - ISO 7811
Smart Card - ISO 7816-2
Card thickness: 10 mil (.25mm) to 60 mil (1.524mm)
Card feeder capacity: 100 cards (30 mil)
Card output hopper capacity: 100 cards (30mil)
Optional card feeder capacity: 220 cards (30mil)

Ribbon Specifications
i Series Printers require the use of i Series ribbons for full color printing
Monochrome: 1500 and 1000 cards/roll
KdO and KrO: 500 cards/roll
YMCK: 400 cards/roll
YMCKO: 200 & 330 cards/roll
1/2 panel YMCKO: 450 cards/roll
Overlay varnishes (clear and hologram): 350 cards/roll

Communications Interface
USB (cable included)
Built-in Ethernet (optional)

Mechanical
Height: 10.1" (256mm)
Depth: 9.4" (239mm)
Width: 18.2" (462mm)
Weight: 15.5 lbs (7.0kg)

Electrical
100 ~ 240 Volts AC, 50 ~ 60 Hz (auto switching)
4 MB image memory standard
FCC Class B, CE, UL and CUL approved

Environmental
Quiet for offices!
Operating Temperature: 60°F to 86°F (15°C to 30°C)
Operating humidity: 20% to 65% non condensing
Storage temperature: 23°F to 158°F (-5°C to 70°C)
Storage Humidity: 20% to 70% non-condensing
Ventilation: Free air

Options
UHF Gen 2 RFID encoder
Smart card contact station (30 mil cards only)
Built-in Ethernet (10/100)
Contactless encoder (MIFARE)
High capacity feeder (220 cards)
Magnetic encoder (20-40 mil cards only)
Extended warranty program
Hot Swap warranty program (USA only)
