Robust Printing and Laminating Speed
Full color printing (YMCK_K) and single sided carrier-based lamination (1.0 mil or 0.6 mil) at 36 seconds per card.

Easy to Use
User friendly operation with two line LCD display indicates printer and laminator status, settings and maintenance functions, patented card cleaning cartridge, and Windows® based printer drivers.

1st In Class with Built-In Ethernet Option
Networking feature provides efficiency, minimal downtime, and ability to locate printer anywhere.

Zebra i Series Intelligent Printing System
Enhanced i Series functionality makes high image quality card printing a simple function for all users.

The system features:
Advanced RFID Technology
Automatic Driver Configuration
Intelligent Color Optimization
Ribbon Image Counter & Ribbon Low Notification
Enhanced Ribbon Formulation

General Specifications
High speed printing with built in laminator
100 cards/hour, color front, black back 1.0 mil laminate
Windows® drivers for 98, NT, 2000, XP
One year printer warranty
One year (unlimited passes) printhead warranty

Color Printing and Laminating
Color dye sublimation or monochrome thermal transfer printing
Under 36 seconds/card, color front, black back 1.0 mil laminate
300 dpi (12 dots/mm) print resolution
Enhanced fourth generation laminator with auto laminate synchronization

Bar Codes
Code 39, Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Interleaved
UPC-A, EAN 8 & EAN 13
PDF-417 2D bar code and other symbologies available via Windows™ drivers

Fonts
True Type fonts available via Windows™ drivers.

Card Specifications
Types: PVC, composite PVC (use composite cards when laminating)
Card width/length: ISO CR-80-ISO 7810, 2.12" (54mm) x 3.38" (86mm)
Magnetic Stripe-ISO 7811
Smart Card-ISO 7816-2
Card thickness: .76mm (30 mil)
Card feeder capacity: 100 cards (30 mil)
Card output hopper capacity: 100 cards (30 mil)

Ribbons
i Series Printers require the use of i Series ribbons for full color printing
Monochrome: 1500 & 1000 cards/roll
Monochrome colors: black, red, blue, green, silver, gold, white
K Resin + O: 500 cards/roll
K DyeSub + O: 500 cards/roll
YMCK: 250 cards/roll
YMCK/K: 200 cards/roll
Note: For optimum printer performance use Genuine Zebra Supplies.

Lamination Specifications
Laminate for full coverage, magnetic stripe cards, and smart cards
Clear and holographic options available
0.6 mil laminate capacity: 170 cards per roll
1.0 mil laminate capacity: 100 cards per roll
Clear laminate for dual-sided cards (front full coverage and back 1/2 patch for magnetic stripe cards-50 cards)
Optional Custom Security Features
Holographic images, OVI and UV images
Note: For optimum laminator performance use Genuine Zebra Supplies.

Communications Interface
USB with Centronics Parallel
Built-in Ethernet Option

Mechanical
Full metal enclosure with viewing window
Width: 32.75in (832mm)*
Depth: 9.25in (235mm)
Height: 10.43in (265mm)
Weight: 47lbs (21.45kg)

Electrical
100 ~ 240 Volts AC, 50 ~ 60 Hz (auto switching)
4 MB image memory standard
FCC Class A, CE, UL and CUL approved

Environmental
Operating Temperature: 60°F to 86°F (15°C to 30°C)
Operating Humidity: 20% to 65% non-condensing
Storage Temperature: 23°F to 158°F (-5°C to 70°C)
Storage Humidity: 20% to 70% non-condensing
Ventilation: Free air

Options
Built-in Ethernet
Smart card contact station (30 mil cards only)
Magnetic encoder
Extended warranty program
On-Site warranty program and Depot warranty programs
Cleaning supplies

*Without output hopper
