Budget-Friendly

Low initial investment
Intuitive design reduces training costs

Easy-to-Use

ATM style CardSense™ single-card feed
Load-N-Go™ ribbon cartridge makes ribbon installation simple and quick
iSeries™ auto-ribbon detection automatically configures printer for optimized imaging and includes a low ribbon warning indicator for convenience
LCD screen displays printer status and diagnostics
Simple USB plug-and-play setup

Versatile and Compact

Full-color or monochrome printing
Magnetic encoder (optional) - 3 Track HiCo/LoCo
Contact or contactless smart card encoders (optional)
Sleek, compact and lightweight design fits in a variety of environments
Integrated card storage conveniently holds up to 100 cards and a cleaning roll

General Specifications
CardSense™ single-card feed
Load-N-Go™ drop-in ribbon cartridge
16-digit LCD display
Windows® Drivers: 2000, XP, Server 2003; Vista compatible
100-card covered holder
Two (2) year warranty on card printer and original printhead (unlimited passes) - if shipped on or after January 1, 2007
One (1) year warranty applies to printers shipped prior to January 1, 2007

Printing
Color dye sublimation or monochrome thermal transfer printing
Single-card feed - 6 seconds per card monochrome
Single-card feed - 35 seconds per card full-color single-sided (YMCKO)
300 dpi (11.8 dots/mm) print resolution

Bar Codes
Code 39, Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Interleaved
UPC-A, EAN 8 & EAN 13
PDF-417 2D bar code and other symbologies can be printed via Windows drivers

Card Specifications
Types: PVC, PVC Composite
Card width/length: ISO CR-80-ISO 7810, 2.12" (54mm) x 3.38" (86mm)
Magnetic Stripe-ISO 7811
Smart Card-ISO 7816
Card thickness: 20 mil (.508mm) to 40 mil (1.02mm)

Ribbon Specifications
Load-N-Go ribbon cartridge with integrated card-cleaning roller
i Series ribbon intelligent technology
YMCKO: 200 cards/cartridge
Monochrome: 1000 cards/cartridge in black, blue, green, gold, red or silver; 850 cards/cartridge white

Communications Interface
USB 1.1 (cable included)
Built-in 10/100 Mbps Ethernet (optional)

Mechanical
Width: 7.9 in (201mm)
Depth: 12.9 in (328mm)
Height: 9.25 in (235mm)
Weight: 10 lbs (4.5kg)

Electrical
100 ~ 240 Volts AC, 50 ~ 60 Hz (auto switching)
8MB image memory standard
FCC Class A, CE, UL and CUL approved

Environmental
Operating Temperature: 60°F to 86°F (15°C to 30°C)
Operating Humidity: 20% to 65% non-condensing
Storage Temperature: 23°F to 158°F (-5°C to 70°C)
Storage Humidity: 20% to 70% non-condensing
Ventilation: Free air

Options
Built-in 10/100 Mbps Ethernet
Magnetic encoder - 3 track HiCo/LoCo
Smart card contact encoder: ISO 7816 (EMV compliant)
Smart card contactless encoder: MIFARE®
Starter Kit (200 - 30 mil PVC cards and 1YMCKO ribbon)
