| Power supply voltage |
100 - 250 V ac, 50/60 Hz |
|
| DC input to scanner |
+ 12 V dc, 600 mA |
|
|
|
| Interfaces |
Depending on scanner version |
|
|
Interface port 1: RS232 or IBM RS485 |
|
|
Interface port 2: OCIA or KBW |
|
| Auxiliary port |
Secondary scanner (250 mA max.) |
|
|
| Light source |
Visible laser diode (655nm) |
|
|
| Scan pattern |
5 directions scan field, 15 lines scan pattern |
|
| Scan rate |
1500 scans / second |
|
|
| Bar code types |
EAN/UPC/JAN + Add-on |
|
|
Code 128, EAN 128, Code 39, Code 32, Codabar, ITF |
|
|
|
| Dimensions |
L x W x D: 240 x 205 x 75 mm |
|
|
: 9.45 x 8.07 x 2.95 inch |
|
|
| Operating temperature |
0° C ~ 40° C |
|
| Humidity |
0% ~ 95% RH (non-condensing) |
|
|
| Laser safety |
IEC 825-1 (1993) Class I, U.S. 21CFR1040 Class IIa |
|
| Electrical safety |
EN 60950 second edition |
|
|
UL1950 (third edition), c-UL (according CSA22.2.950-95) |
|
|
|
| Radio and TV interference |
EN 55022 Class B (1994), FCC part 15 Class A (1992) |
|
| Harmonic current emissions |
EN 61000-3-2 (1995) |
|
| EM-immunity |
EN 50082-1 (1992) based on: |
|
| ElectroStatic Discharge (ESD) |
IEC 801-2 (1991) |
|
| Radio frequency immunity |
IEC 801-3 (1984) / ENV 50140 (1993) |
|
| Electrical fast transient |
IEC 801-4 (1988) |
|
