Product

B110A

B210A
B310A
B410A
B610A

B120A

Color

Black

Blue/Red/Brown/Green

Black

TTR grade

Wax-Resin

Wax-Resin

Wax-Resin

Resistance to smear and heat

50°c(122 F)

50°c(122 F)

35°c(95 F)

Features

·  High resolution

·  50°c corrugated cardboard scrape resistance

·  B110A's color variation

·  High resolution

·  50°c corrugated cardboard scrape resistance

·  High resolution

·  About 100 sec. rough paper will be acceptable

Applications

·  General use when barcode readability is specifically required.

·  Strong against high temperature and vibration during transportation and suitable for delivery and distribution control.

·  Identification in inventory control.

·  Printing corporate logo.

·  General use when barcode readability is specifically required.

·  For business cards, postcards and tickets, most of which have rough paper.

Product

B120E

B130EV

Color

Black

Black

TTR grade

Wax-Resin

Wax-Resin

Resistance to smear and heat

30°c(86 F)

40°c(95 F)

Features

·  High resolution

·  For low-smoothness paper

·  High resolution

·  High-speed printing
(10 to 12"/s)

Applications

·  General use when barcode readability is specifically required.

·  For low-smoothness paper like tickets.

·  Edge head which can print at high speed makes it suitable for high-volume printing.

Product

MB110A

MB110B

Color

Black

Black

Resistance to smear and heat

Non-smearless

Non-smearless

Features

·  Repeated usage for five times or more

·  Barcode readable (when coated paper RP050 is used)

·  Resource saver, low waste.

·  Repeated usage for five times or more

·  For low-smoothness paper (e.g. ATB tickets)

·  Resource saver, low waste.

Applications

·  General barcode labels (Running cost reduction and environmental protection)

·  ATB, transportation tickets (Running cost reduction and environmental protection)

Product

130ED

Color

Black

TTR grade

Wax-Resin

Features

·  For PE, PP, PET, Nylon

·  Ultrahigh-speed printing (20 to 24"/s)

·  High image density

Applications

·  General packages for food.

·  Date printing for foods like bread and pasta which require high-speed, high-volume printing.

·  Clear image is possible even on transparent package because printed image blocks light.

Product

120HS

Color

Black

TTR grade

Resin

Features

·  For PE,PP

·  High image density

·  Scratch resistance

Applications

·  Suitable for PE, PP which are main packaging materials for food.

·  Clear image is possible even on transparent package because printed image blocks light.

·  No spoiling of image during transportation and handling of food.

Product

D110A

Color

Black

TTR grade

Resin

Features

·  For nylon

·  High heat resistance

Applications

·  Suitable for heat-resistant nylon packages which are often boiled.

Product

B110C

B110CR

Color

Black

Black

TTR grade

Resin

Resin

Resistance to smear and heat

100°c(212 F)

100°c(212 F)

Features

·  100°c corrugated cardboard scrape resistance

·  Solvent resistance (ethanol, kerosene, engine oil)

·  Ultra solvent resistance (for application requires more higher solvent resistance than B110C)

·  600DPI resolution

Applications

·  For nameplate which is cleaned with alcohol when being finished.

·  For automobile manufacturing process control

·  For small characters & barcodes in name plate.

·  For super duty use

Product

B110CU

RFR-W

Classifl-cation

TTR

Specified receiving material

Color

Black

White

TTR grade

Resin

Designed for B110CU
Base material:PP base

Features

·  Ultra chemicalresistance (ethanol,IPA,acetone,MEX,thinner,xylene,brake-fluid,water)

·  100°c corrugated cardboard scrape resistance

·  Scratch resistance

·  UL approval

·  Thermal printing becomes possible even in processes where many solvents are used.

Applications

·  For transportation equipment,parts nameplate,process control where heavy solvent is used for finish cleaning.

·  For chemical label on drum or container which is exposed to heavy solvents.

·  For medical applications(e.g.control diagnostic of pathologic histology)

Product

B120EC

Color

Black

TTR grade

Resin

Resistance to smear and heat

100°c(212 F)

Features

·  100°c corrugated cardboard scrape resistance

·  Solvent resistance (ethanol, kerosene,engine oil)

·  Scratch resistance

Applications

·  For nameplate which is cleaned with alcohol when being finished.

·  For automobile manufacturing process control

·  For contacting hard items like cards and rental videocassettes.

Product

RPR

Base material

Paper based

Basis Weight g/m2

69±8

Thickness µm

78±8

Features

·  Finest print productivity with RICOH's WAX/RESIN, RESIN ribbons

·  Water resistance

·  Chemical resistance

Applications

·  Name plate,identification label

·  Serial# label for appliances and peripherals

·  Drum label

Product

D110A

D210A

D310A

Color

Black

Navy

Red

TTR grade

Resin

Resin

Resin

Features

·  Printing on cloth (nylon, polyester, acetate)

·  Wash resistance
Water: 80°c, 20 minutes
Dry cleaning: Perchloroethylene 40°c, 30 minutes

·  Ironing resistance (150°c)

·  Printing on cloth (nylon, polyester, acetate)

·  Wash resistance
Water: 80°c, 20 minutes
Dry cleaning: Perchloroethylene 40°c, 30 minutes

·  Ironing resistance (150°c)

·  Printing on cloth (nylon, polyester, acetate)

·  Wash resistance
Water: 80°c, 20 minutes
Dry cleaning: Perchloroethylene 40°c, 30 minutes

·  Ironing resistance (150°c)

Applications

·  Care label, linen and cloth products (e.g. seatbelt, mop, mat) indication label.

·  Navy color printing on care label for underwear.

·  Corporate logo printing on care label.

·  Identification for washing and distribution.

·  Care label prohibition X mark

·  Corporate logo printing on care label.

·  Identification for washing and distribution.

Product

B120HS

D110A
D210A
D310A

Color

Black

Black/Navy/Red

TTR grade

Resin

Resin

Features

·  For polyolefine film like PP, PE

·  For film like PI (polyimide), PET

·  High heat resistance

·  Solvent resistance (gasoline, kerosene, engine oil)

Applications

·  Suitable for usage of PP, PE for process control label, the surface of which is not treated for purposes of cost reduction.

·  Heat-resistant application such as 200°c steaming process for blood
formulation agent.

·  Color coding identification for process control.
