Standard Features

• Print methods: Direct thermal/thermal transfer (TLP)
• Construction: ABS double-walled casing
• OpenACCESS™ design
• Head-up sensor
• Windows® drivers (95, 98, Me, NT4.0, NT2000, XP)
• Windows printer utilities
• Zebra Printer Management

Resolution
203 dpi (8 dots/mm)
Memory

• Standard: 256 KB SRAM; 512 KB Flash
• Optional: 512 KB SRAM; 1 MB Flash

Print width
4.09" (104 mm) maximum
Print length

• 11" (279 mm) with standard memory
• 22" (584 mm) with expanded memory

Print speed
4" (102 mm)/sec
Media sensors
Reflective
Transmissive

Maximum label and liner width
4.25" (108 mm)
2.8" (71 mm) with Media Adapter Guides
Minimum label and liner width
1.00" (25.4 mm)
0.585" (15 mm) with Media Adapter Guides
Maximum label and liner length
11" (279 mm) (with standard memory)
Maximum label and liner length (optional)
22" (558 mm)
Maximum roll diameter
5" (127 mm)
Core diameter
1.0" (25.4 mm) and 1.5" (38 mm)
Media thickness
0.003" (.08 mm) to 0.007" (0.18 mm)
Media types
(black-mark optional), black bar, black mark, continuous, continuous receipt, die-cut, fanfold, gap, notch, notch sensing, notched, perforated, receipt, roll-fed, tag, tag stock

Outside diameter
1.34" (34 mm)
Standard length
244' (74 m)
Ratio
1:1 media roll to ribbon ratios
Ribbon width

• Recommended to be at least as wide as media
• 1.33" (33.8 mm) to 4.30" (110 mm)

Ribbon setup
Ribbon wound ink side out
ID Core
0.5" (12.7 mm)

Operating temperature
TT: Operating temperature 40° F (5° C) to 105° F (41° C) Thermal transfer
DT: Operating temperature 40° F (5° C) to 105° F (41° C) Direct thermal
Storage temperatures
-40° F (-40° C) to 140° F (60° C)
Operating humidity
10-90% non-condensing R.H.
Storage humidity
5-95% non-condensing R.H.
Electrical

• Autoranging external power supply with C7 type connector
• Output: 20 VDC, 2.5 A
• Input: 100-200 VAC, 50-60 Hz

Agency approvals

• UL
• FCC
• VCCI/PSE
• C-TICK
• CSA
• NOM
• CE
• CCC/SRRC
• GOST-R

Width
7.9" (201 mm)
Height
6.8" (173 mm)
Depth
9.75" (248 mm)
Weight
3.2 lbs (1.5 kg)
Shipping weight
5.8 lbs (2.6 kg)

Options

• Cutter
• Real time clock
• Internal ZebraNet PrintServer II for Ethernet connectivity
• Dispenser with label taken sensor
• Asian Font Set

Communication and Interface Capabilities

• Serial RS-232 (DB9)
• Parallel (Centronics)
• USB
• ZebraNet PrintServer II for Ethernet connectivity (internal or external)

Core programming languages
EPL2

Linear
Code 39
Code 128 with subsets A/B/C
Code 93
Codabar
Interleaved 2-of-5
UPC-E
UPC-A
UPC-A and UPC-E with 2 or 5 digit extensions
EAN-13
EAN-8
EAN-8 and EAN-13 with 2 or 5 digit extensions
Postnet
Plessey
German Post Code
RSS-14
MSI-3
2-dimensional
MaxiCode
MicroPDF417
MacroPDF417
QR Code (requires Asian version printer)
Data Matrix
Fonts and Graphics

• Standard Fonts: 5 bitmapped, expandable 8x
• Soft font storage in Flash memory
• DOS Code Pages Supported: 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
• Windows Code Pages Supported: 1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257
